Commercial Atta Pulverizer
5HP Double Chamber Atta Chakki Pulverizer Machine
₹2,15,000
Model VM-A5
Vimash 5 HP Atta Pulverizer is a commercial atta chakki machine designed for businesses that need reliable flour grinding. This atta chakki machine uses stoneless grinding technology for consistent atta production and is built for regular commercial use. The heavy-duty atta pulverizer is suitable for grinding wheat and other dry grains. If you are looking for a commercial atta chakki or atta chakki machine for your flour grinding business, the Vimash 5 HP model is a reliable choice.
- Capacity
- 40-60KG
- Main motor
- 5 HP
- Power use
- 4KW
Technical data
Full specifications
| Grinding Capacity Per-Hrs | 40-60KG |
|---|---|
| Automation Grade | Automatic |
| Material | SS -MS |
| Power Source | Electric |
| Voltage-V | 440-V |
| Current A | 7.5 |
| Corrosion Resistance | Yes |
| Power Consumption | 4KW |
| Motor Speed | 1440 RPM |
| Frequency Hz | 50Hz |
| Motor Type | Three Phase |
| Coating | Powder Coating |
| Big Chamber Diameter | 10"x5" |
| Small Chamber Diameter | 8"x4' |
| Machine Dimension | H-46", W-20", L-56" |
| Main Motor | 5 HP |
| Cyclone Motor | 0.5 & 0.5 HP |
| Machine Weight | 185 KG APPROX |
| Air Lock Weight | 110KG APPROX |
Features
Built-in advantages
- Double chamber grinding for finer, uniform flour
- Powder coated SS / MS body with corrosion resistance
- Three phase 440 V, 50 Hz operation
- Twin cyclone assembly for dust-free discharge
- Automatic operation with low maintenance
- Easy screen change for multiple mesh grades
Applications
Where it is used
Commercial flour mills and atta chakki unitsWheat, bajra, jowar, rice and pulses grindingBesan and dal flour productionGrocery stores, co-operatives and franchise chakkis
