Commercial Masala Pulverizer
10HP Masala Grinder Haldi Grinder Machine with Cyclone
₹4,25,000
Model VM-M10
The 10 HP masala pulverizer with cyclone handles 80 – 100 kg/hr of spices at a beater speed of 3840 RPM. Its double chamber and stainless contact zones keep volatile oils and aroma intact while the twin cyclone assembly discharges powder without dust in the workspace.
- Capacity
- 80 – 100 kg/hr
- Main motor
- 10 HP
- Power use
- 7.5 KW
Technical data
Full specifications
| Grinding Capacity Per-Hrs | 80 – 100 kg/hr |
|---|---|
| Automation Grade | Automatic |
| Material | SS -MS |
| Power Source | Electric |
| Voltage-V | 440 V |
| Current A | 15 |
| Corrosion Resistance | Yes |
| Power Consumption | 7.5 KW |
| Motor Speed | 1440 RPM |
| Frequency Hz | 50Hz |
| Motor Type | Three Phase |
| Coating | Powder Coating |
| Big Chamber Diameter | 14"x7" |
| Small Chamber Diameter | 9"x4" |
| Machine Dimension | H-51", W-28", L-59" |
| Main Motor | 10 HP |
| Cyclone Motor | 0.5 HP & 1 HP |
| Machine Weight | 212 KG APPROX |
| Air Lock Weight | 110 KG APPROX |
Features
Built-in advantages
- Cyclone unit with beater speed of 3840 RPM
- Semi-automatic operation with simple controls
- Powder coated SS / MS body, corrosion resistant
- Cool grinding that protects spice aroma and oils
- Three phase 440 V, 50 Hz motor with 1440 RPM
- Quick-access chamber for cleaning between batches
Applications
Where it is used
Chilli, turmeric, coriander and cumin grindingMasala blending and packaging unitsDry herb, sugar and salt pulverizingSpice traders and small-to-mid scale food plants
